Designed for housing associations, parking facilities and commercial properties. This is best solution if many vehicles needs to be charged at the same time and the system needs advanced features.
Article number
27001
Temperature range
-30°C to +50°C
Material
PC/ASA, PA6 and PC
Weight
2.20 kg without wallmount
2.90 kg with wallmount
Dimensions
H: 273 x W: 220 x D: 100
Protection grade
UV resistant
IP45 protection rating
IK10 impact protection
UL94-V0 flame resistance
Installation
Enua Charge can be mounted by anyone on a pre-installed Enua Wallmount.
Installation voltage
TN, IT and TT
230VAC ± 10 %
400VAC ± 10 %
RCD
Integrated MRCD Type B (IEC 60947-2, Annex M)
30mA AC and 6mA DC
Overcurrent protection
32A integrated (IEC 60269-2)
Maximum power
22 kW @ 32 A/3-phase (TN-grid)
12,7 kW @ 32 A/3-phase (IT-grid)
7,4 kW @ 32 A/1-phase (IT/TN-grid)
Protection class
Protection class I
Overvoltage category III (4 kV)
Charging connector
Type 2 female connector (IEC 62196-2).
Electronically locked during charging.
Energy measurement
3-phase active energy meter
±1 % accuracy
Communication interface
TE-M, NB-IoT, WiFi 2,4 GHz, RFID/NFC
(Connection fee may apply for LTE connectivity)
Software interface
Enua App for users and installers.
Third-party integration options OCPP2.0.1 cloud.
(Subscription fee may apply)
