Article number

27004

Temperature range

-30°C to +50°C

Material

PC/ASA, PA6 and PC

Weight

2.20 kg without wallmount
2.90 kg with wallmount

Dimensions

H: 273 x W: 220 x D: 100

Protection grade

UV resistant
IP45 protection rating
IK10 impact protection
UL94-V0 flame resistance

Installation

Enua Charge E can be mounted by anyone on a pre-installed Enua Wallmount.Enua Charge E supports communication and load balancing in installations with up to 10 Enua Wallmounts.

Installation voltage

TN, IT and TT
230VAC ± 10 %
400VAC ± 10 %

RCD

Integrated MRCD Type B (IEC 60947-2, Annex M)
30mA AC and 6mA DC

Overcurrent protection

32A integrated (IEC 60269-2)

Maximum power

22 kW @ 32 A/3-phase (TN-grid)
12,7 kW @ 32 A/3-phase (IT-grid)
7,4 kW @ 32 A/1-phase (IT/TN-grid)

Protection class

Protection class I
Overvoltage category III (4 kV)

Charging connector

Type 2 female connector (IEC 62196-2).
Electronically locked during charging.

Energy measurement

3-phase active energy meter
±1 % accuracy

Communication interface

TE-M, NB-IoT, WiFi 2,4 GHz, RFID/NFC
(Connection fee may apply for LTE connectivity)

Software interface

Enua App for users and installers.
Third-party integration options OCPP2.0.1 cloud.
(Subscription fee may apply)
